Feature / Screw-in Thermocouples | PVC cable | Silicone cable | PFA cable | Glass fibre cable | ||
Measurement Range | -30 °C to +105 °C | -50 °C to +180 °C | -50 °C to +260 °C | -50 °C to +400 °C | ||
Cable Material | PVC | Silicone | PFA | Glass Fibre | ||
Cable color | White/black/red/green/brown…… | |||||
IP Protection Class | IP54 | IP65 | IP54 | IP20 | ||
Probe Diameter | 6 mm | 6 mm | ||||
Thread | G1/2",G1/4 " G3/8 " | |||||
Mounting Length(mm) | 50 mm, 100 mm, 150 mm, 200 mm, 250 mm, 300 mm, 400 mm， 500 mm | |||||
Cable Length(m) | 1,2,3,4,5,10,15,20 | |||||
Available Measuring elements | Thermocouple Type K | |||||
Connection Type | 2-Wire, Mini-TC connector Type K bk, TC connector Type K bk | |||||
Fill in Your Customizable sensor order below:
Cable Material | Cable color/Thread | Cable/mounting Length | Measuring element | Connection Type |
Others | ||||
